| PART# : 3VU1340-1MF00 |
| Product series: 3UV |
| Tripper Rated Current: 0.6-1A |
| Poles: 3P |
| Installation method: rail type |
| Product certification: CCC |
| Arc extinguishing medium: air |
| Rated insulation voltage: 750 |
| Wiring method: wiring in front of the board |
| Operation mode: manual operation |
| Structure: Molded shell |
| Speed: Normal type |
| Rated frequency: 50/60HZ |
| Part number: 3VU1340-1MF00 |
| Order number: 3VU1340-1MF00 |
| Small package quantity: 1pc/box |
| Protection mode: motor control and protection |
| Rated limit short-circuit breaking capacity Icu: 50KA |
| Rated current setting range: 0.6-1A |
| Large short circuit breaking capacity: 50KA |
| Series: 3UV |
| 3C certificate number: 2010010309449426 |
| Model: 3VU1340-1MF00 |
| Auxiliary contact type: 1 [1NO1NC auxiliary contact] |
| Working altitude: 3000m |
| Working Ambient Temperature: -20..... 55 |
| Dimensions: Standard |
| Mechanical life: 100,000 times |
| Electrical life: 100,000 times |
| Weight: 0.26kg |
| Shell Current: 25A |
| Shell Class Rated Current (A): 25A |
| Rated voltage: 690V |
