Product Overview
Space savings are achieved by placing this voltage regulator in the 8-SOIC (0.154, 3.90mm Width) Exposed Pad package. There are 1 outputs on DC DC switching regulator. Adjusting voltage regulator's output pins generate Adjustable output. There is a switching regulator that is compatible with the Surface Mount mounting. As long as its operating temperature is -20°C ~ 125°C (TJ), dc to dc voltage regulator should perform well. There is a switching frequency of 340kHz for this voltage regulator 12v. Input voltage 4.5V is the dc to dc voltage regulator's minimum input voltage required for operation of the voltage regulators. The output voltage (Min/Fixed) of this voltage regulator 12v is 0.925V. This voltage regulator 12v offers maximum design flexibility with an output current of 3A. The maximum input voltage of this voltage regulator 12v is 27V. There is a possibility that DC DC switching regulator can give voltage at 0.925 to 21.6 V volts. On the basis of the maximum output voltage of 21.6V, adjusting voltage regulator can be operated easily. The switching DC-DC regulator belongs to the - family of electronic voltage regulator 12vs. 3 A is normally the output current ofDC DC switching regulator.
Product Features
1 outputs
Product Applications
LSP5523-R8A Voltage Regulators applications.
-
Automation technology
-
CMM
-
Various precision measuring instruments
-
Various precision measuring detectors
-
Flaw detection equipment
-
Balance equipment
-
Industrial robots
-
Industrial controllers
-
Die casting equipment
-
Injection molding machinery
Product Description
| Type | Description |
| ANSC PART# | ANSC- LSP5523-R8A |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - DC DC Switching Regulators | |
| Mfr | Original |
| Series | - |
| Packaging | Bulk |
| Part Status | Active |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 27V |
| Voltage - Output (Min/Fixed) | 0.925V |
| Voltage - Output (Max) | 21.6V |
| Current - Output | 3A |
| Frequency - Switching | 340kHz |
| Synchronous Rectifier | Yes |
| Operating Temperature |
-20°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | 8-SOP-EP |
| Base Product Number | LSP5523 |
