General Description The CD40106BC Hex Schmitt Trigger is a monolithic complementary MOS (CMOS) integrated circuit constructed with N and P-channel enhancement transistors. Features ■Wide supply voltage range: 3V to 15V ■High noise immunity: 0.7 VDD(typ.) ■Low power TTL compatibility: Fan out of 2 driving 74L or 1 driving 74LS ■Hysteresis: 0.4 VDD(typ.), 0.2 VDD guaranteed ■Equivalent to MM74C14 ■Equivalent to MC14584B |
Product Description
| Type# | Description |
| ANSC PART# | ANSC- CD40106BF |
| Ihs Manufacturer | Original |
| Part Package Code | DIP |
| Package Description | DIP, DIP14,.3 |
| Pin Count | 14 |
| Samacsys Manufacturer | Original |
| Family | 4000/14000/40000 |
| Length | 19.56 mm |
| Load Capacitance (CL) | 50 pF |
| Logic IC Type | INVERTER |
| Max I(ol) | 0.001 A |
| Number of Functions | 6 |
| Number of Inputs | 1 |
| Number of Terminals | 14 |
| Operating Temperature-Max |
125 °C |
| Operating Temperature-Min | -55 °C |
| Package Body Material | CERAMIC, GLASS-SEALED |
| Package Code | DIP |
| Package Equivalence Code | DIP14,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Packing Method | TUBE |
| Power Supply Current-Max (ICC) | 0.03 mA |
| Prop. Delay@Nom-Sup | 0.28 ns |
| Propagation Delay (tpd) | 280 ns |
| Qualification Status | Not Qualified |
| Schmitt Trigger | YES |
| Seated Height-Max | 5.08 mm |
| Supply Voltage-Max (Vsup) | 18 V |
| Supply Voltage-Min (Vsup) | 3 V |
| Supply Voltage-Nom (Vsup) | 5 V |
| Surface Mount | NO |
| Technology | CMOS |
| Temperature Grade | MILITARY |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Width | 7.62 mm |
