Product Descriptions
The XC95288XL is a 3.3V CPLD targeted for high-performance, low-voltage applications in leading-edge communications and computing systems. It is comprised of 16 54V18 Function Blocks, providing 6,400 usable gates with propagation delays of 6 ns.
Product Features
? 6 ns pin-to-pin logic delays
? System frequency up to 208 MHz
? 288 macrocells with 6,400 usable gates
? Available in small footprint packages
- 144-pin TQFP (117 user I/O pins)
- 208-pin PQFP (168 user I/O pins)
- 256-pin BGA (192 user I/O pins)
- 256-pin FBGA (192 user I/O pins)
- 280-pin CSP (192 user I/O pins)
- Pb-free available for all packages
? Optimized for high-performance 3.3V systems
- Low power operation
- 5V tolerant I/O pins accept 5V, 3.3V, and 2.5V signals
- 3.3V or 2.5V output capability
- Advanced 0.35 micron feature size CMOS Fast FLASH? technology
? Advanced system features
- In-system programmable
- Superior pin-locking and routability with Fast CONNECT? II switch matrix
- Extra wide 54-input Function Blocks
- Up to 90 product-terms per macrocell with individual product-term allocation
- Local clock inversion with three global and one product-term clocks
- Individual output enable per output pin with local inversion
- Input hysteresis on all user and boundary-scan pin inputs
- Bus-hold circuitry on all user pin inputs
- Full IEEE Standard 1149.1 boundary-scan (JTAG)
? Fast concurrent programming
? Slew rate control on individual outputs
? Enhanced data security features
? Excellent quality and reliability
- Endurance exceeding 10,000 program/erase cycles
- 20 year data retention
- ESD protection exceeding 2,000V
? Pin-compatible with 5V-core XC95288 device in the 208-pin HQFP package
Specifications
| Attribute | Attribute value |
| Model | ANSC-M2502212395 |
| Product Model | XC95288XL-10TQG144I |
| Manufacturer: | AMD |
| Product Category: | CPLD - Complex Programmable Logic Devices |
| Shipping Restrictions: | Mouser does not presently sell this product in your region. |
| RoHS: | Details |
| Series: | XC95288XL |
| Mounting Style: | SMD/SMT |
| Package / Case: | TQFP-144 |
| Operating Supply Voltage: | 3.3 V |
| Number of Macrocells: | 288 Macrocell |
| Number of I/Os: | 117 I/O |
| Minimum Operating Temperature: | - 40 C |
| Maximum Operating Temperature: | + 85 C |
| Maximum Operating Frequency: | 208 MHz |
| Propagation Delay - Max: | 10 ns |
| Brand: | AMD / Xilinx |
| Memory Type: | Flash |
| Moisture Sensitive: | Yes |
| Number of Gates: | 6400 |
| Number of Logic Array Blocks - LABs: | 16 |
| Operating Supply Current: | 85 mA |
| Product Type: | CPLD - Complex Programmable Logic Devices |
| Factory Pack Quantity: | 60 |
| Subcategory: | Programmable Logic ICs |
| Supply Voltage - Max: | 3.6 V |
| Supply Voltage - Min: | 3 V |
| Unit Weight: | 0.775879 oz |
