Product Details
GENERAL DESCRIPTION
The SSM2135 dual audio operational amplifier permits excellent performance in portable or low power audio systems, with an operating supply range of 4 V to 36 V or ±2 V to ±18 V.
The unity-gain stable device has very low voltage noise of 5.2 nV/√Hz, and total harmonic distortion plus noise below 0.01% over normal signal levels and loads. Such characteristics are enhanced by wide output swing and load drive capability.
FEATURES
Excellent sonic characteristics
High output drive capability
5.2 nV/√Hz equivalent input noise @ 1 kHz
0.003% THD + N (VOUT = 1 V p-p @ 1 kHz)
3.5 MHz gain bandwidth
Unity-gain stable
Low cost
APPLICATIONS
Multimedia audio systems
Microphone preamplifiers
Headphone drivers
Differential line receivers
Balanced line drivers
Audio ADC input buffers
Audio DAC l-V converters and filters
Pseudoground generators
Product Description
| Type | Description |
| ANSC PART# | ANSC - SSM2135SZ |
| Category | Integrated Circuits (ICs) |
| Linear | |
| Amplifiers | |
| Instrumentation, Op Amps, Buffer Amps | |
| Mfr | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Amplifier Type | Audio |
| Number of Circuits | 2 |
| Output Type | - |
| Slew Rate | 0.9V/μs |
| Gain Bandwidth Product | 3.5 MHz |
| Current - Input Bias | 300 nA |
| Voltage - Input Offset | 200 μV |
| Current - Supply | 3.7mA |
| Current - Output / Channel | 30 mA |
| Voltage - Supply Span (Min) | 4 V |
| Voltage - Supply Span (Max) | 36 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | SSM2135 |
