Product Introduction

The MAX30102 is an integrated pulse oximetry and heart-rate monitor module. It includes internal LEDs, photodetectors, optical elements, and

low-noise electronics with ambient light rejection. The MAX30102 provides a complete system solution to ease the design-in process

for mobile and wearable devices.

The MAX30102 operates on a single 1.8V power supply and a separate 3.3V power supply for the internal LEDs. Communication is through a

standard I2C-compatible interface. The module can be shut down through software with zero standby current, allowing the power rails to

remain powered at all times.

Product Features

● Heart-Rate Monitor and Pulse Oximeter Sensor in LED Reflective Solution

● Tiny 5.6mm x 3.3mm x 1.55mm 14-Pin Optical Module

? Integrated Cover Glass for Optimal, Robust Performance

● Ultra-Low Power Operation for Mobile Devices

? Programmable Sample Rate and LED Current for Power Savings

? Low-Power Heart-Rate Monitor (< 1mW)

? Ultra-Low Shutdown Current (0.7μA, typ)

● Fast Data Output Capability

? High Sample Rates

● Robust Motion Artifact Resilience

? High SNR

● -40°C to +85°C Operating Temperature Range

Product Applications

● Wearable Devices

● Fitness Assistant Devices

● Smartphones

● Tablets
