Product Overview
Shipping overseas is convenient due to the electrical component's packing in 16-DIP (0.300, 7.62mm). This packaging method provides high reliability because it uses advanced packaging techniques. Multiplexers like this are mounted in the Through Hole position. Multiplexers and demultiplexers have a number of circuits 8:1. Operational temperature extended around -55°C~125°C TA. 16 terminations have been made so far. Due to its 1 channels, the electrical component produces high-quality output. When a voltage supply of 4.5V is used, the electronic component should be turned on and run. It is injected into the electrical part body with 16 pins. It consists of 1 circuits. Try searching for the analog switch ic with 74HC4051 if you are looking for variants. As far as internal resistance is concerned, it has 160Ohm. To find out what the functions of 16 pins are, please refer to their datasheets. Users shouldn't supply more than 6V voltage to the switch device. An effective Dual, Single supply digital multiplexer. It is recommended that the electrical component receives a voltage of 2V. Despite this switch's dual supply capability, its voltage should not exceed 5V. When using dual power supplies, you should attach at least 1V. A SINGLE-ENDED MULTIPLEXER analog IC is integrated into the board. The 8 inputs need to be operated in order to work. There is 160Ohm resistance between Drain and Source for this electronic part.
Product Features
1 Channels
Drain-to-Source resistance: 160Ohm
Product Applications
CD74HC4051E Analog Switches & Multiplexers ICs applications.
Automatic test equipment
Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
Existing multiplexer applications (both fault-protected and nonfault-protected)
New designs requiring multiplexer functions
Product Description
| Type | Description |
| ANSC PART# | ANSC- CD74HC4051E |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Analog Switches, Multiplexers, Demultiplexers | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:01 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 130Ohm |
| Channel-to-Channel Matching (ΔRon) | 8.5Ohm |
| Voltage - Supply, Single (V+) | 2V ~ 6V |
| Voltage - Supply, Dual (V±) | ±1V ~ 5V |
| Switch Time (Ton, Toff) (Max) | - |
| -3db Bandwidth | 180MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 25pF |
| Current - Leakage (IS(off)) (Max) | 400nA |
| Crosstalk | - |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-PDIP |
| Base Product Number | 74HC4051 |
