MMUN2233LT1G Description
The ON Semiconductor MMUN2232LT1G is a 3-pin SOT-23 (TO236) NPN digital transistor. A single digital transistor and its external resistor bias network are intended to be replaced.
MMUN2233LT1G Features
The base input resistor is 10Kohm
The base-emitter resistor is 10kohm
Collector emitter voltage VCEO of 50VDC
Simplifies circuit design
Compact board space
Reduced component count
AEC-Q101 qualified
The continuous collector current of 100mAdc
MMUN2233LT1G Applications
Industrial
Portable Devices
Consumer Electronics
Power Management
Product Description
ansc Part # | ANSC- MMUN2233LT1G |
Part# | MMUN2233LT1G |
Type： | Transistors |
Manufactor | onsemi |
DC | new |
Package / Case | SOT-23-3 |
Supplier Device Package | Tape & Reel (TR)Cut Tape (CT) |
Description | Discrete Semiconductor ProductsTransistorsBipolar (BJT)Single, Pre-Biased Bipolar TransistorsonsemiSOT-23-3Tape & Reel (TR)Cut Tape (CT) |
Actual image of the product
Specifications
| TYPE | DESCRIPTION |
|---|---|
| Category | Discrete Semiconductor ProductsTransistorsBipolar (BJT)Single, Pre-Biased Bipolar Transistors |
| Mfr | onsemi |
| Series | - |
| Package | Tape & Reel (TR)Cut Tape (CT) |
| Product Status | Active |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 100 mA |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
| Resistor - Base (R1) | 4.7 kOhms |
| Resistor - Emitter Base (R2) | 47 kOhms |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 5mA, 10V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 300μA, 10mA |
| Current - Collector Cutoff (Max) | 500nA |
| Power - Max | 246 mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 (TO-236) |
| Base Product Number | MMUN2233 |
