TLV1117CDCYRG3 Overview
A Tape & Reel (TR) case is used to deliver this IC regulator. This voltage regulator IC comes in a TO-261-4, TO-261AA case. On the regulater IC chip, there are a total of 4 terminations. Output type Adjustable. This component features 1 Voltage regulators. As a result of the Linear Voltage Regulator's design, the operating temperature of Surface Mount can be adjusted within a specified range. There is a temperature range of 0°C~125°C degrees during operation of the IC regulator. There is a configuration in this voltage regulator IC that specifies that its output function is Positive. A total of 4 pins can be found on the board. In order to deliver prompt, sufficient and reliable performance, this regulator IC has 1 outputs in total. A dropout voltage of 10 volts can be obtained from this voltage regulator IC. There are 4 pins on the chip. As an FYI, this IC voltage regulator has the basic part number TLV1117. As you can see from the picture, the regulator IC is packed in a certain way. Taking into account the operation requirements, the maximum output current of the IC voltage regulator reaches 800mA. It operates in the 1.7mA Quiescent Current state.
TLV1117CDCYRG3 Features
1.2V dropout voltage
TR method of packing
TLV1117CDCYRG3 Applications
There are a lot of Texas Instruments
TLV1117CDCYRG3 Linear Voltage Regulators applications.
Video equipment
CPU power supply
Switching regulator
Multiple-power supply system
Digital audio player
Digital TV
Smartcard
Industrial equipment
DVD and CD-ROM drive
Quick charge protocols
Product Description
Texas Instruments TLV1117CDCYRG3 Adjustable TO-261-4, TO-261AA Tape & Reel (TR) Regulator IC 4 Adjustable 2.3mm TLV1117 PMIC 4 TO-261-4, TO-261AA
ansc Part # | ANSC- TLV1117CDCYRG3 |
Part# | TLV1117CDCYRG3 |
Type： | Integrated Circuits (ICs) |
Manufactor | Texas Instruments |
DC | new |
Package / Case | SOT-223-4 |
Supplier Device Package | Tape & Reel (TR)Cut Tape (CT) |
Description | Integrated Circuits (ICs)Power Management (PMIC)Voltage Regulators - Linear, Low Drop Out (LDO) RegulatorsTexas InstrumentsSOT-223-4Tape & Reel (TR)Cut Tape (CT) |
Actual image of the product
Specifications
| TYPE | DESCRIPTION |
|---|---|
| Category | Integrated Circuits (ICs)Power Management (PMIC)Voltage Regulators - Linear, Low Drop Out (LDO) Regulators |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR)Cut Tape (CT) |
| Product Status | Active |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 15V |
| Voltage - Output (Min/Fixed) | 1.25V |
| Voltage - Output (Max) | 13.7V |
| Voltage Dropout (Max) | 1.3V @ 800mA |
| Current - Output | 800mA |
| Current - Quiescent (Iq) | 10 mA |
| PSRR | 75dB (120Hz) |
| Control Features | - |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | 0°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | TO-261-4, TO-261AA |
| Supplier Device Package | SOT-223-4 |
| Base Product Number | TLV1117 |
