Product Applications
? Hard Disk Drives
? Notebook Computers
? Battery-Powered Devices
? Portable Instrumentation
Product Benefits and Features
? Wide Input Voltage Range (2.7 V to 10 V)
? All WSON Options are Available as AEC-Q100 Grade 1
? 2 PERCENT Output Accuracy (25°C)
? Low Dropout Voltage: 250 mV at 500 mA (Typical,5 V Out)
? Precision (Trimmed) Bandgap Reference
? Ensured Specifications for –40°C to 125°C
? 1-μA Off-State Quiescent Current
? Thermal Overload Protection
? Foldback Current Limiting
? Ground Pin Current: 55 μA (typical) at full load
? Enable Pin (LP38693)
Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-LP38691DTX-5.0 |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - Linear, Low Drop Out (LDO) Regulators | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel? | |
| Product Status | Obsolete |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 10V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.45V @ 500mA |
| Current - Output | 500mA |
| Current - Quiescent (Iq) | 55 μA |
| Current - Supply (Max) | 100 μA |
| PSRR | 55dB (120Hz) |
| Control Features | - |
| Protection Features | Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252-3 |
| Base Product Number | LP38691 |
