Product Descriptions
The XA Zynq? UltraScale+? MPSoC family is based on the UltraScale? MPSoC architecture. This family of products integrates a feature-rich 64-bit quad-core Arm? Cortex?-A53 and dual-core Arm Cortex-R5 based processing system (PS) and programmable logic (PL) UltraScale architecture in a single device. Also included are on-chip memory, multiport external memory interfaces, and a rich set of peripheral connectivity interfaces.
Product Features
? Quad-core
? CPU frequency: Up to 1.2GHz
? Extendable cache coherency
? Armv8-A Architecture
o 64-bit or 32-bit operating modes
o TrustZone security
o A64 instruction set in 64-bit mode,
A32/T32 instruction set in 32-bit mode
? NEON Advanced SIMD media-processing engine
? Single/double precision Floating Point Unit (FPU)
? CoreSight? and Embedded Trace Macrocell (ETM)
? Accelerator Coherency Port (ACP)
? AXI Coherency Extension (ACE)
? Power island gating for each processor core
? Timer and Interrupts
o Arm Generic timers support
o Two system level triple-timer counters
o One watchdog timer
o One global system timer
? Caches
o 32KB Level 1, 2-way set-associative instruction cache with parity (independent for each CPU)
o 32KB Level 1, 4-way set-associative data cache with ECC (independent for each CPU)
o 1MB 16-way set-associative Level 2 cache with ECC (shared between the CPUs)
Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-XCZU5EG-1SFVC784I |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| System On Chip (SoC) | |
| Mfr | AMD |
| Series | Zynq? UltraScale+? MPSoC EG |
| Package | Tray |
| Product Status | Active |
| Architecture | MCU, FPGA |
| Core Processor | Quad ARM? Cortex?-A53 MPCore? with CoreSight?, Dual ARM?Cortex?-R5 with CoreSight?, ARM Mali?-400 MP2 |
| Flash Size | - |
| RAM Size | 256KB |
| Peripherals | DMA, WDT |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG |
| Speed | 500MHz, 600MHz, 1.2GHz |
| Primary Attributes | Zynq?UltraScale+? FPGA, 256K+ Logic Cells |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Package / Case | 784-BFBGA, FCBGA |
| Supplier Device Package | 784-FCBGA (23x23) |
| Number of I/O | 252 |
| Base Product Number | XCZU5 |
